Luoyang Guorun Pipes Co.,Ltd
|
High quality PE80 or PE100 /Polythene /PE pipe
| Payment Terms: | T/T,L/C |
| Place of Origin: | Henan, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
1. Material: High quality PE80 or PE100 /Polythene /PE
2. Competitive price, favorable quality
3. Promote shipment
As professional manufactuer of HDPE pipe, we can supply the HDPE pipe as following:
Size range of HDPE pipe:20-800mm
Material: high density PE80/PE100
Pressure range of HDPE pipe:0.6/0.8/1.0/1.25/1.6Mpa
Working temperature: -20°C-40°C
Colors: Black with blue strip or on request
Elongation at Break(%):≥350 Longitudinal Reversion 110°C(%):≤3
Oxidation Induction Time(200°C), min: ≥20
Hydrostatic Test: No Leakage
Table of wall thickness for your reference--- PE100 water supply pipe.
Outer Diameter dn(mm) | Wall Thickness en(mm) | ||||
SDR26 0.6MPa | SDR21 0.8MPa | SDR17 1.0MPa | SDR13.6 1.25MPa | SDR11 1.6MPa | |
20 | 2.3 | ||||
25 | 2.3 | ||||
32 | 3.0 | ||||
40 | 3.7 | ||||
63 | 4.7 | 5.8 | |||
75 | 4.5 | 5.6 | 6.8 | ||
90 | 4.3 | 5.4 | 6.7 | 8.2 | |
140 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 12.1 | 15.0 | 18.7 | 23.2 | 28.6 |
400 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
500 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 |
630 | 24.1 | 30.0 | 37.4 | 46.3 | 57.2 |
